PUR 98 W

Wall mounted rangehood with EasySwitch light-touch switches for convenient operation and LED lighting
  • Timeless design – stainless steel canopy 898 mm wide
  • Powerful – 790 m3/h in Booster setting
  • Efficient filtration – 10-layer stainless-steel grease filter
  • Safe and easy to clean – Miele CleanCover
  • Suitable for every home – for extraction or recirculation
See Full Description
$ 3,199.00
In stock
PUR 98 W
Description
10456810
  • Timeless design – stainless steel canopy 898 mm wide
  • Powerful – 790 m3/h in Booster setting
  • Efficient filtration – 10-layer stainless-steel grease filter
  • Safe and easy to clean – Miele CleanCover
  • Suitable for every home – for extraction or recirculation
Benefits
Always on the safe side
Safety switch-off
Always on the safe side
Sensible, even in case of operating errors: the rangehood switches off automatically after 10 hours.
Easy to use and effective against grease
Stainless steel grease filters (10-layer)
Easy to use and effective against grease
Looks great and does a good job: effective grease filtering and easy cleaning in a dishwasher.
Convenience and safety in detail
Miele CleanCover
Convenience and safety in detail
Protection and easy cleaning: the smooth concealed surface prevents contact with electrical components and motor.
Specification
Colour
Stainless steel
RAL colours available as customisation on request
Customisation possible on request
Overall height for vented and external in in. (mm)
685
Overall height for extraction mode and external mode rangehoods in mm
1005
Overall height for recirculation in in. (mm)
815
Overall height for recirculation mode rangehoods in mm
1135
Canopy width in in. (mm)
898
Canopy height in in. (mm)
62
Depth of hood canopy in in. (mm)
500
Net weight in kg
25
Length of supply lead in m
1.5
Standard plug fitted
Total rated load in kW
0.304
Voltage in V
230
Fuse rating in A
10
Frequency in Hz
50
Number of phases
1
Non-return flap
Type of air guide
Can be retrofitted
Recirculation conversion kit (order separately)
DUW 20
Active charcoal filter (order separately)
DKF 12-P
Electronic controls
Power levels (number without Booster level)
3
Programmable Booster level switch-off
Easy-to-clean canopy interior – CleanCover
Extraction ducting connection at top
Extraction connection at top and rear
Diameter of extraction ducting connection in mm
150
Telescopic chimney
Dual-action blower
AC motor
Air throughput in Level 1 (m³/h) according to EN 61591
290
Air throughput in Level 2 (m³/h) according to EN 61591
420
Air throughput in Level 3 (m³/h) according to EN 61591
570
Air throughput in Booster level (m³/h) according to EN 61591
790
Sound power in Level 1 (dB(A) re 1 pW) according to EN 60704-3
47
Sound power in Level 2 (dB(A) re 1 pW) according to EN 60704-3
54
Noise level on Level 3 (dB(A) re 1 pW) according to EN 60704-3
62
Sound power in Booster level (dB(A) re 1 pW) acc. to EN 60704-3
68
Sound pressure in Level 1 (dB(A) re 20 µPa) according to EN 60704-2-13
34
Sound pressure in Level 2 (dB(A) re 20 µPa) according to EN 60704-2-13
41
Sound pressure in Level 3 (dB(A) re 20 µPa) according to EN 60704-2-13
49
Sound pressure in Booster level (dB(A) re 20 µPa) acc. to EN 60704-2-13
55
Wall-mounted rangehood
Air throughput in Level 1 (m³/h) according to EN 61591
220
Air throughput in Level 2 (m³/h) according to EN 61591
320
Air throughput in Level 3 (m³/h) according to EN 61591
420
Air throughput in Booster level (m³/h) according to EN 61591
470
Sound power in Level 1 (dB(A) re 1 pW) according to EN 60704-3
60
Sound power in Level 2 (dB(A) re 1 pW) according to EN 60704-3
66
Noise level on Level 3 (dB(A) re 1 pW) according to EN 60704-3
71
Sound power in Booster level (dB(A) re 1 pW) acc. to EN 60704-3
74
Sound pressure in Level 1 (dB(A) re 20 µPa) according to EN 60704-2-13
47
Sound pressure in Level 2 (dB(A) re 20 µPa) according to EN 60704-2-13
53
Sound pressure in Level 3 (dB(A) re 20 µPa) according to EN 60704-2-13
61
Sound pressure in Booster level (dB(A) re 20 µPa) acc. to EN 60704-2-13
61
Number of dishwasher-safe stainless steel grease filters (10-ply)
3
LED
Number x W
3 x 3 W
Light intensity in Lx
450 lx
Colour temperature in K
3000 Kelvin
Safety shut-off
Easy-to-clean canopy interior – CleanCover
