PUR 98 W
Wall mounted rangehood with EasySwitch light-touch switches for convenient operation and LED lighting
- Timeless design – stainless steel canopy 898 mm wide
- Powerful – 790 m3/h in Booster setting
- Efficient filtration – 10-layer stainless-steel grease filter
- Safe and easy to clean – Miele CleanCover
- Suitable for every home – for extraction or recirculation
Active Promotions
Description
10456810
- Timeless design – stainless steel canopy 898 mm wide
- Powerful – 790 m3/h in Booster setting
- Efficient filtration – 10-layer stainless-steel grease filter
- Safe and easy to clean – Miele CleanCover
- Suitable for every home – for extraction or recirculation
Benefits
![Always on the safe side](https://media.miele.com/images/2000020/200002048/20000204809.png?imWidth=442&impolicy=z-crop&x=321&y=0&w=4486&h=3366)
Safety switch-off
Always on the safe side
Sensible, even in case of operating errors: the rangehood switches off automatically after 10 hours.
![Easy to use and effective against grease](https://media.miele.com/images/2000020/200002048/20000204833.png?imWidth=442&impolicy=z-crop&x=284&y=0&w=4552&h=3415)
Stainless steel grease filters (10-layer)
Easy to use and effective against grease
Looks great and does a good job: effective grease filtering and easy cleaning in a dishwasher.
![Convenience and safety in detail](https://media.miele.com/images/2000020/200002047/20000204786.png?imWidth=442&impolicy=z-crop&x=464&y=0&w=4554&h=3415)
Miele CleanCover
Convenience and safety in detail
Protection and easy cleaning: the smooth concealed surface prevents contact with electrical components and motor.
Specification
- Colour
- Stainless steel
- RAL colours available as customisation on request
- Customisation possible on request
- Overall height for vented and external in in. (mm)
- 685
- Overall height for extraction mode and external mode rangehoods in mm
- 1005
- Overall height for recirculation in in. (mm)
- 815
- Overall height for recirculation mode rangehoods in mm
- 1135
- Canopy width in in. (mm)
- 898
- Canopy height in in. (mm)
- 62
- Depth of hood canopy in in. (mm)
- 500
- Net weight in kg
- 25
- Length of supply lead in m
- 1.5
- Standard plug fitted
- Total rated load in kW
- 0.304
- Voltage in V
- 230
- Fuse rating in A
- 10
- Frequency in Hz
- 50
- Number of phases
- 1
- Non-return flap
- Type of air guide
- Can be retrofitted
- Recirculation conversion kit (order separately)
- DUW 20
- Active charcoal filter (order separately)
- DKF 12-P
- Electronic controls
- Power levels (number without Booster level)
- 3
- Programmable Booster level switch-off
- Extraction ducting connection at top
- Extraction connection at top and rear
- Diameter of extraction ducting connection in mm
- 150
- Telescopic chimney
- Dual-action blower
- AC motor
- Air throughput in Level 1 (m³/h) according to EN 61591
- 290
- Air throughput in Level 2 (m³/h) according to EN 61591
- 420
- Air throughput in Level 3 (m³/h) according to EN 61591
- 570
- Air throughput in Booster level (m³/h) according to EN 61591
- 790
- Sound power in Level 1 (dB(A) re 1 pW) according to EN 60704-3
- 47
- Sound power in Level 2 (dB(A) re 1 pW) according to EN 60704-3
- 54
- Noise level on Level 3 (dB(A) re 1 pW) according to EN 60704-3
- 62
- Sound power in Booster level (dB(A) re 1 pW) acc. to EN 60704-3
- 68
- Sound pressure in Level 1 (dB(A) re 20 µPa) according to EN 60704-2-13
- 34
- Sound pressure in Level 2 (dB(A) re 20 µPa) according to EN 60704-2-13
- 41
- Sound pressure in Level 3 (dB(A) re 20 µPa) according to EN 60704-2-13
- 49
- Sound pressure in Booster level (dB(A) re 20 µPa) acc. to EN 60704-2-13
- 55
- Wall-mounted rangehood
- Air throughput in Level 1 (m³/h) according to EN 61591
- 220
- Air throughput in Level 2 (m³/h) according to EN 61591
- 320
- Air throughput in Level 3 (m³/h) according to EN 61591
- 420
- Air throughput in Booster level (m³/h) according to EN 61591
- 470
- Sound power in Level 1 (dB(A) re 1 pW) according to EN 60704-3
- 60
- Sound power in Level 2 (dB(A) re 1 pW) according to EN 60704-3
- 66
- Noise level on Level 3 (dB(A) re 1 pW) according to EN 60704-3
- 71
- Sound power in Booster level (dB(A) re 1 pW) acc. to EN 60704-3
- 74
- Sound pressure in Level 1 (dB(A) re 20 µPa) according to EN 60704-2-13
- 47
- Sound pressure in Level 2 (dB(A) re 20 µPa) according to EN 60704-2-13
- 53
- Sound pressure in Level 3 (dB(A) re 20 µPa) according to EN 60704-2-13
- 61
- Sound pressure in Booster level (dB(A) re 20 µPa) acc. to EN 60704-2-13
- 61
- Number of dishwasher-safe stainless steel grease filters (10-ply)
- 3
- LED
- Number x W
- 3 x 3 W
- Light intensity in Lx
- 450 lx
- Colour temperature in K
- 3000 Kelvin
- Safety shut-off
- Easy-to-clean canopy interior – CleanCover
