PUR 98 W Wall mounted cooker hood
Wall mounted rangehood with EasySwitch light-touch switches for convenient operation and LED lighting
- Timeless design – stainless steel canopy 898 mm wide
- Powerful – 790 m3/h in Booster setting
- Efficient filtration – 10-layer stainless-steel grease filter
- Safe and easy to clean – Miele CleanCover
- Suitable for every home – for extraction or recirculation
Active Promotions
Description
10456810
- Timeless design – stainless steel canopy 898 mm wide
- Powerful – 790 m3/h in Booster setting
- Efficient filtration – 10-layer stainless-steel grease filter
- Safe and easy to clean – Miele CleanCover
- Suitable for every home – for extraction or recirculation
Benefits
Miele CleanCover
Convenience and safety in detail
Protection and easy cleaning: the smooth concealed surface prevents contact with electrical components and motor.
Miele CleanCover
Convenience and safety in detail
Located behind the grease filters is the Miele CleanCover: Instead of sharp metal edges and electrical components you will find only a sealed, smooth surface. It is particularly easy to clean and protects you from coming in contact with electrical components and the motor. Miele attention to detail - for your convenience and safety.
Stainless steel grease filters (10-layer)
Easy to use and effective against grease
Looks great and does a good job: effective grease filtering and easy cleaning in a dishwasher.
Stainless steel grease filters (10-layer)
Easy to use and effective against grease
Miele rangehoods are equipped with 10-ply stainless-steel grease filter(s) for excellent grease removal. Built-in fall protection allows you to handle them safely and protects your cooktop from damage. The top layer and filter frame are made of high-quality stainless steel so that no visible discoloration occurs from being cleaned in the dishwasher and they retain their stunning appearance.
Safety switch-off
Always on the safe side
Sensible, even in case of operating errors: the rangehood switches off automatically after 10 hours.
Safety switch-off
Always on the safe side
The rangehood will switch off automatically after 10 hours. This ensures maximum safety even in the event of operating errors.
Miele CleanCover
Convenience and safety in detail
Protection and easy cleaning: the smooth concealed surface prevents contact with electrical components and motor.
Miele CleanCover
Convenience and safety in detail
Located behind the grease filters is the Miele CleanCover: Instead of sharp metal edges and electrical components you will find only a sealed, smooth surface. It is particularly easy to clean and protects you from coming in contact with electrical components and the motor. Miele attention to detail - for your convenience and safety.
Stainless steel grease filters (10-layer)
Easy to use and effective against grease
Looks great and does a good job: effective grease filtering and easy cleaning in a dishwasher.
Stainless steel grease filters (10-layer)
Easy to use and effective against grease
Miele rangehoods are equipped with 10-ply stainless-steel grease filter(s) for excellent grease removal. Built-in fall protection allows you to handle them safely and protects your cooktop from damage. The top layer and filter frame are made of high-quality stainless steel so that no visible discoloration occurs from being cleaned in the dishwasher and they retain their stunning appearance.
Specification
- Colour
- Stainless steel
- RAL colours available as customisation on request
- Customisation possible on request
- Variable height available as customisation on request
- Variable width available as customisation on request
- Overall height for vented and external in in. (mm)
- 685
- Overall height for extraction mode and external mode rangehoods in mm
- 1005
- Overall height for recirculation in in. (mm)
- 815
- Overall height for recirculation mode rangehoods in mm
- 1135
- Canopy width in in. (mm)
- 898
- Canopy height in in. (mm)
- 62
- Depth of hood canopy in in. (mm)
- 500
- Net weight in kg
- 25
- Length of supply lead in m
- 1.5
- Standard plug fitted
- Total rated load in kW
- 0.304
- Voltage in V
- 230
- Fuse rating in A
- 10
- Frequency in Hz
- 50
- Number of phases
- 1
- Non-return flap
- Type of air guide
- Can be retrofitted
- Recirculation conversion kit (order separately)
- DUW 20
- Active charcoal filter (order separately)
- DKF 12-P
- Electronic controls
- Power levels (number without Booster level)
- 3
- Programmable Booster level switch-off
- Extraction ducting connection at top
- Extraction connection at top and rear
- Diameter of extraction ducting connection in mm
- 150
- Telescopic chimney
- Dual-action blower
- AC motor
- Air throughput in Level 1 (m³/h) according to EN 61591
- 290
- Air throughput in Level 2 (m³/h) according to EN 61591
- 420
- Air throughput in Level 3 (m³/h) according to EN 61591
- 570
- Air throughput in Booster level (m³/h) according to EN 61591
- 790
- Sound power in Level 1 (dB(A) re 1 pW) according to EN 60704-3
- 47
- Sound power in Level 2 (dB(A) re 1 pW) according to EN 60704-3
- 54
- Noise level on Level 3 (dB(A) re 1 pW) according to EN 60704-3
- 62
- Sound power in Booster level (dB(A) re 1 pW) acc. to EN 60704-3
- 68
- Sound pressure in Level 1 (dB(A) re 20 µPa) according to EN 60704-2-13
- 34
- Sound pressure in Level 2 (dB(A) re 20 µPa) according to EN 60704-2-13
- 41
- Sound pressure in Level 3 (dB(A) re 20 µPa) according to EN 60704-2-13
- 49
- Sound pressure in Booster level (dB(A) re 20 µPa) acc. to EN 60704-2-13
- 55
- Wall-mounted rangehood
- Air throughput in Level 1 (m³/h) according to EN 61591
- 220
- Air throughput in Level 2 (m³/h) according to EN 61591
- 320
- Air throughput in Level 3 (m³/h) according to EN 61591
- 420
- Air throughput in Booster level (m³/h) according to EN 61591
- 470
- Sound power in Level 1 (dB(A) re 1 pW) according to EN 60704-3
- 60
- Sound power in Level 2 (dB(A) re 1 pW) according to EN 60704-3
- 66
- Noise level on Level 3 (dB(A) re 1 pW) according to EN 60704-3
- 71
- Sound power in Booster level (dB(A) re 1 pW) acc. to EN 60704-3
- 74
- Sound pressure in Level 1 (dB(A) re 20 µPa) according to EN 60704-2-13
- 47
- Sound pressure in Level 2 (dB(A) re 20 µPa) according to EN 60704-2-13
- 53
- Sound pressure in Level 3 (dB(A) re 20 µPa) according to EN 60704-2-13
- 61
- Sound pressure in Booster level (dB(A) re 20 µPa) acc. to EN 60704-2-13
- 61
- Number of dishwasher-safe stainless steel grease filters (10-ply)
- 3
- LED
- Number x W
- 3 x 3 W
- Light intensity in Lx
- 450 lx
- Colour temperature in K
- 3000 Kelvin
- Safety shut-off
- Easy-to-clean canopy interior – CleanCover
